DATA, TV & PHONE POINTS
MELTON & EYNESBURY
A solid connection makes everything easier, from streaming in the living room to working from home. Properly run TV, data and phone points mean no dropouts, no mess and outlets exactly where you want them.
DTW installs TV antenna points, data and network cabling and phone outlets for homes and businesses, including extra points during renovations and fit outs.
Licensed Electrician for Data, TV & Phone Points in Melton & Eynesbury
TIME TO CALL IF…
DATA & TV POINT INSTALLATION PROCESS
PLAN CABLE ROUTES
We plan routes through roof cavities and walls to keep cabling hidden. We discuss point locations with you to ensure they end up exactly where you need them.
RUN AND TERMINATE CABLES
Cat6 data cables and coaxial TV cables are run, terminated cleanly into wall plates and labelled. No surface run trunking unless there's genuinely no other option.
TEST EVERY POINT
Data points are tested with a cable tester before we leave. TV points are checked for signal. You know everything is working before we pack up.
DATA AND TV CABLING DONE RIGHT
Structured cabling is one of those jobs where the difference between a good install and a poor one is invisible until something stops working. Cat6 run properly, kept away from mains cabling and terminated to spec, will carry gigabit reliably for the life of the house. The same cable pulled tight around a corner and stapled next to a power circuit will not.
CAT6 AND THE 90 METRE LIMIT
A structured cabling channel has a maximum permanent link length of 90 metres. In a house that is rarely a constraint, but in a long build or out to a shed it can be, and it changes where the patch panel needs to live.
SEPARATION FROM MAINS
Data cable run alongside power cable picks up interference and can be a safety issue if the insulation is compromised. Correct separation is a wiring rules requirement, not a preference, and it is one of the most commonly ignored details in cheap cabling.
REGISTERED CABLER REQUIREMENT
Any cabling connected to the telecommunications network has to be installed by an ACMA registered cabler. That is a legal requirement rather than a quality claim, and it is worth confirming whoever does your data work actually holds it.
TV SIGNAL AND SPLITTING
Every split in a TV signal loses level. Feeding four rooms from one antenna without amplification is where pixelating and dropouts come from. The fix is measuring the signal at the antenna and designing the distribution to suit, not adding splitters and hoping.
A CENTRAL PATCH POINT
Running every data outlet back to one location, usually a cabinet or a shallow enclosure in a wardrobe or garage, is what makes the cabling worth having. It means outlets can be repurposed, the router can move without new cable, and a fault can be isolated to one run. Star wiring from a central point costs marginally more at install and is the difference between cabling and a mess.
NEED DATA, TV & PHONE POINTS?
Tell us about the job and you'll get a straight answer and an honest quote, fast, with no obligation.
DATA, TV & PHONE POINTS FAQs
Can you add a TV point to another room?
Yes. We run a new outlet wherever you want it and make sure the signal is strong and clean.
Do you run data and network cabling?
Yes, we install hardwired data and network points, ideal for home offices and reliable connections.
Can this be done during a renovation?
Absolutely. Adding data, TV and phone points during a reno is the tidiest time to do it, with cables concealed in the walls.
Can you run data cabling to a shed or garage?
Yes. We can run Cat6 or coaxial cabling to outbuildings, underground in conduit where required. A solid wired connection is always more reliable than Wi Fi extenders.
What's the difference between Cat5e and Cat6 data cabling?
Cat6 supports higher speeds and is better shielded against interference. For new installations we always recommend Cat6, the price difference is minimal and it future proofs the cabling.
SUBURBS WE SERVICE
Data, TV & Phone Points available across Melton, western suburbs and beyond. Free quotes, same tradesman every time.
